Komatsu XS Series Weld-on Corner Adapter-Spade 1250XS70L/1250XS70R

Long wear parts@ supply high quality Komatsu XS Series Weld-on Corner Adapter-Spade. Our aftermarket replacement Komatsu XS Series Spade corner adapters are heavy-duty mining-grade weld-on corner base specially engineered for Komatsu XS premium mining tooth system. Different from standard flat corner adapters, it features a unique extended spade flange structure that stretches outward to fully wrap and protect the bucket corner plate. It is engineered to match Komatsu XS series bucket teeth with rotary locking pin system,  are widely fitted for large‑size and mining‑class Komatsu excavators such as PC650,PC800, PC1000, PC1250,PC2000.

Komatsu spade adapters 1040MXS30L/ 1040MXS30R are compatible with bucket teeth XS30RC/XS30TL, and use pin assembly XS30P to fix;

Komatsu spade adapters 1200XS40L/ 1200XS40R are compatible with bucket teeth XS40RC/XS40TL, and use pin assembly XS40P to fix;

Komatsu spade adapters 1200XS50L/1200XS50R/1200XS50RWC/ 1200XS50LWC are compatible with bucket teeth XS50RC/ XS50TL, and use pin assembly XS50P to fix;

Komatsu spade adapters 1250XS50L/1250XS50R/1250XS50RWC/ 1250XS50LWC are compatible with bucket teeth XS50RPX/ XS50PC, and use pin assembly XS50P to fix;

Komatsu spade adapters 1250XS70L/1250XS70R/1250XS70RWC/1250XS70LWC are compatible with bucket teeth XS70RC/ XS70TL, and use pin assembly XS70P to fix;

Komatsu spade adapters 1275XS70L/1275XS70R/1275XS70RWC/ 1275XS70LWC are compatible with bucket teeth XS70RPX/ XS70PC, and use pin assembly XS70P to fix;

Komatsu spade adapters 1080MXS70L/ 1080MXS70R are compatible with bucket teeth XS70RC/XS70RPX, and use pin assembly XS70P to fix;

Our aftermarket  Komatsu XS spade-style adapters are designed exclusively for severe mining conditions with heavy side abrasion, lateral impact, and eccentric rock scraping. It effectively solves the most common bucket corner failure issues: side wear thinning, corner chipping, weld peeling and lip deformation.
Our factory adopt high‑strength low‑alloy cast steel with precision quenching‑and‑tempering heat treatment , the hardness of adapter are stable around 360‑420HB , impact strength ≥22J .All of our bucket adapters are manufactured under ISO 9001 certified quality management systems, every adapter undergoes rigorous quality control—including material composition analysis, hardness verification, dimensional inspection to eliminate internal casting defects.

Except  Komatsu XS‑series bucket adapters , we can also supply you Komatsu other series bucket adapters . Except Komatsu GET parts ,we can also supply you GET Parts & Wear parts for other brands , include Caterpillar /ESCO /Sany / Hyundai/ Hitachi/ Liebherr/ Hensley /VOLVO/ Liugong/ Xugong/ MTG/Kobelco and so on . Welcome to contact me for more details !
