Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of Cutting edge, Segment ,Half arrow,Spade Nose Base Edge,Protector compatible with all makes and models of Caterpillar loaders .
Long wear parts supply full range of bolt-on and weld-in blades , edge design includes Single bevel flat edge(SBF), Wide Bevel flat edge(WBF),Double bevel flat edge(DBF).
Part number
Alternative number
Description
Dimension
Hole
1016776
101-6776
Base Edge With Segment Holes
4.000 x 21.142 x 244.882
1016777
101-6777
Corner LH/RH for 1250800 Protectors
8E3157
8E-3157
Segment
2.000 x 27.500 x 17.500
5
1004012
100-4012
HD Segment
3.000 x 27.500 x 17.500
5
8E3160
8E-3160
Rear Wear Plate
2.375 x 16.000 x 47.000
4
2A6724
2A-6724
Weld-On Behind Heel Wear Plate
0.750 x 17.625 x 14.500
3
1U0740
1U-0740
Sidebar Protector
2.125 x 6.313 x 23.813
2
1073383
107-3383
Center Base Edge Wear Plate
3.000 x 21.500 x 22.000
5
6I8804
6I-8804
J800 Weld-On Adapter
10.433 x 8.661 x 27.303
1031833
103-1833
Segment
3.000 x 21.500 x 17.500
5
1031834
103-1834
Segment RH
3.000 x 21.500 x 23.625
5
1031835
103-1835
Segment LH
3.000 x 21.750 x 23.625
5
1099030
109-9030
HA Segment (Cast)
3.500 x 26.750 x 17.323
5
1176805
117-6805
HA Segment RH (Cast)
3.500 x 26.750 x 17.323
5
1176806
117-6806
HA Segment LH (Cast)
3.500 x 26.750 x 17.323
5
1957230
195-7230
Bolt on Top Plate Center
1.500 x 13.059 x 17.500
5
1957231
195-7231
Bolt on Top Plate RH
1.500 x 13.500 x 17.101
5
1957232
195-7232
Bolt on Top Plate LH
1.500 x 13.500 x 17.101
5
1004015
100-4015
Heavy Duty Wear Plate
3.000 x 14.750 x 47.000
4
1324714
132-4714
Hex Bolt Wear Plate
x x 47.000
1441281
144-1281
Bolt-On Behind Heel Wear Plate
3.000 x 18.000 x 14.500
3
1441282
144-1282
Bolt-On Behind Heel Wear Plate
3.000 x 18.000 x 14.500
3
1250800
125-0800
Sidebar Protector
2.750 x 8.500 x 40.000
2
9W4493
9W-4493
Center Base Edge Wear Plate
2.375 x 16.000 x 40.250
9
6Y0022
6Y-0022
Center Base Edge Wear Plate
2.375 x 16.000 x 30.875
7
1042001
104-2001
End Base Edge Wear Plate
2.500 x 12.125 x 29.625
6
