Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of Cutting edge, Segment ,Half arrow,Spade Nose Base Edge,Protector compatible with all makes and models of Caterpillar loaders .
Long wear parts supply full range of bolt-on and weld-in blades , edge design includes Single bevel flat edge(SBF), Wide Bevel flat edge(WBF),Double bevel flat edge(DBF).
Part number
Alternative number
Description
Dimension
Hole
9V6571
9V-6571
Base Edge With Segment Holes
1.000 x 9.620 x 81.890
28
4V8335
4V-8335
Base Edge For Bolt-on Edges or Teeth
1.000 x 9.625 x 81.890
16
9V6570
9V-6570
Base Edge With Segment Holes
1.000 x 9.625 x 86.813
28
4V8850
4V-8850
Base Edge For Bolt-on Edges or Teeth
1.000 x 9.625 x 86.813
16
4V1544
4V-1544
Corner 1 hole RH
1.000 x 8.270 x 8.150
1
4V1545
4V-1545
Corner 1 hole LH
1.000 x 8.270 x 8.150
1
6I8310
6I-8310
Corner 2 hole RH
1.500 x 8.641 x 8.125
2
6I8311
6I-8311
Corner 2 hole LH
1.500 x 8.641 x 8.125
2
2530060
253-0060
New Style 2 Hole Corner Protector RH
0.875 x 8.313 x 12.250
2
2530061
253-0061
New Style 2 Hole Corner Protector LH
0.875 x 8.313 x 12.250
2
1U0294
1U-0294
Center
1.000 x 11.000 x 34.625
3
1U0293
1U-0293
Center
1.000 x 11.000 x 37.000
3
4T9563
4T-9563
Center
1.000 x 11.000 x 38.125
3
4T8091
4T-8091
End
1.000 x 13.563 x 6.250
2
4T8079
4T-8079
Multi purpose dozer center
0.625 x 8.000 x 81.125
13
4T6691
4T-6691
Segment
1.000 x 11.000 x 6.875
2
4T6692
4T-6692
Segment
1.000 x 11.000 x 7.688
2
4T6692HA
4T-6692HA
HA Segment (Cast)
1.375 x 10.875 x 7.688
2
4T6693
4T-6693
End Segment
1.000 x 11.000 x 8.250
2
4T6693HA
4T-6693HA
HA Segment (Cast)
1.375 x 10.875 x 8.250
2
6W2976
6W-2976
Base Edge With Segment Holes
1.000 x 9.625 x 88.500
28
8V7453
8V-7453
Base Edge For Bolt-on Edges or Teeth
1.000 x 9.620 x 88.500
16
4T8072
4T-8072
Multi purpose dozer center
0.625 x 8.000 x 59.875
10
4T8082
4T-8082
Multi purpose dozer end
0.625 x 8.000 x 13.750
3
