Products information 1)Material: Carbon steel or Manganese steel or boron steel 2)Surface: yellow paint or gray paint or as your request 3)Hardness: HB280-500 or HB320~360 or HB440~500 4)Technique: forging, machining, heat treatment 5) Package: strong plywood pallet 6) Application :used in a wide variety of applications across all Caterpillar,Komatsu , Shantui graders,bulldozers,loader buckets .Multiple edge models to match your applications and job site's needs .
Long wear parts product line includes a comprehensive array of cutting edges & end bits compatible with all makes and models of bulldozers .Long wear parts offer a diverse array of blade types including Boron steel dozer Cutting Edge,Manganese dozer Cutting Edge,Carbon steel dozer Cutting Edge,Boron steel dozer End Bit,Manganese dozer End Bit,Carbon steel dozer End Bit .
Part number
Alternative number
Description
Dimension
Hole
3428851
342-8851
Center
0.750 x 8.000 x 43.835
7
3G4282
3G-4282
Center
0.750 x 8.000 x 45.375
7
1774550
177-4550
Center
0.750 x 8.000 x 58.898
9
4T2315
4T-2315
Center
0.750 x 8.000 x 61.250
10
1273050
127-3050
Center
10
1774551
177-4551
Level Cut End Bit RH
0.750 x 8.000 x 21.220
4
1774552
177-4552
Level Cut End Bit LH
0.750 x 8.000 x 21.220
4
1406787
140-6787
Hot Cup End Bit RH
0.875 x 9.625 x 21.000
4
1406788
140-6788
Hot Cup End Bit LH
0.875 x 9.625 x 21.000
4
4T5407
4T-5407
Cast End Bit RH
1.000 x 10.000 x 21.000
4
4T5408
4T-5408
Cast End Bit LH
1.000 x 10.000 x 21.000
4
3G4285
3G-4285
Level Cut End Bit LH/RH
0.750 x 8.000 x 16.750
4
8E9379
8E-9379
Level Cut End Bit RH
1.000 x 8.000 x 18.500
4
8E9378
8E-9378
Level Cut End Bit LH
1.000 x 8.000 x 18.500
4
8E9502
8E-9502
Dozer Blade/End Bit Support
0.750 x 6.693 x 124.354
22
8E9377
8E-9377
Center
0.625 x 8.000 x 41.500
7
2944519
294-4519
Dozer Foldable Center
0.625 x 8.000 x
3710758
371-0758
Dozer Foldable Center
0.750 x 8.000 x
5
4T8940
4T-8940
Center
0.625 x 8.000 x 47.000
8
2971705
297-1705
Dozer Foldable Center
0.625 x 8.000 x
5
8E7245
8E-7245
Center
0.625 x 8.000 x 53.400
9
3710786
371-0786
Dozer Foldable Center
0.625 x 8.000 x
6
3000168
300-0168
Dozer Foldable Side End Bit
0.625 x 8.000 x
2971699
297-1699
Dozer Foldable Side End Bit
0.625 x 8.000 x
7
