Products information 1)Idler roller body material: 35Mn/35MnB/40Cr/#45Carbon steel 2)Surface hardness: HRC52-60 ;Hardened layer:5~7mm; 3)Shaft material: 40Cr/42CrMo 4)Shaft Hardness: HRC54-60,Hardened layer:2~4mm; 5)Tensile Strength:≥600MPa;Yield Strength:≥350MPa; 6)Impact Toughness: ≥30J/cm2（normal temperature） 7)Package: packed in strong pallets 8)Application: idlers guide the track in and out of the track rollers. They intermittently support the machine's weight and provide a way to c
Long wear parts@ supply high quality Caterpillar Front Idler/Caterpillar Idler Group/ Caterpillar Track Idler/ Caterpillar Idler Wheel/ Caterpillar Idler Roller.
Long wear parts@ idler wheel is forged from high-quality alloy steels—such as 35Mn, 35MnB, or 40Cr—offering exceptional strength and toughness to resist fracture.
The wheel tread undergoes intermediate-frequency induction hardening, achieving a hardness of HRC 52–60; the hardened layer is uniform, ensuring excellent wear resistance without spalling.
Precision machining ensures superior coaxiality, resulting in smooth, vibration-free operation that minimizes track wear.
The wheel body features an optimized structural design that provides excellent resistance to both impact and fatigue, ensuring stable performance even under the heavy-load conditions typical of mining operations.
Reliable sealing effectively prevents the ingress of dust and water, thereby extending the service life of the internal bearings and bushings.
Long wear parts@idler groups are compatible with Caterpillar(CAT) /Komatsu /ESCO /Sany /Doosan/ Hyundai/ Hitachi/ Liebherr/ Hensley /VOLVO/ Liugong/ Xugong/ MTG/JCB/H&L/Combi/ Case/John deere/Kobelco/Fiat/Sumitomo/ Bobcat/Samsung machines and so on.
Model
Part number
Alternative No.
Description
D6R/D6T
1343952
134-3952
Caterpillar Idler Group
D7F-G / without bracket
7T4509
7T-4509
Caterpillar Idler Group
D7F-G / without bracket
1S8186
1S-8186
Caterpillar Idler Group
D7H (585mm)
6Y2031
6Y-2031
Caterpillar Idler Group
D7H (585mm)
1359896
135-9896
Caterpillar Idler Group
D7H (628mm)
9W7647
9W-7647
Caterpillar Idler Group
D8H-K
9S7221
9S-7221
Caterpillar Idler Group
D8N ( 698mm)
1111730
111-1730
Caterpillar Idler Group
D8N ( 698mm)
9W9989
9W-9989
Caterpillar Idler Group
D8N ( 698mm)
6Y0557
6Y-0557
Caterpillar Idler Group
D8N ( 620mm )
1111729
111-1729
Caterpillar Idler Group
D8N ( 620mm )
6Y0554
6Y-0554
Caterpillar Idler Group
